Specifications
Yamaha F200 V6 3.3L four strokes set the course for today’s offshore power.
- Engine Type: 60 deg. V6 DOHC 24-Valve
- Displacement: 204.6 ci (3352 cc)
- Bore x Stroke: 94 x 80.5 mm (3.70 x 3.17 in.)
- Prop Shaft Horsepower: 200 hp at 5500 rpm (VF200LA)
- Compression Ratio: 9.9:1
- Fuel/Induction System: EFI/VCT/DOHC
- Exhaust: Through Propeller
- Intake: Single Throttle Valve
- Ignition System: TCI Micro Computer
- Spark Plug: LFR6A-11-00-000
- Alternator Output: 44 Amp (Battery charge: 27 Amp)
- Starting System: T = Electric w/ PTT
- Lubrication: Wet Sump
- Engine Oil Capacity: 4.7L/4.5L w/without filter
- Full Throttle RPM Range: 5000 – 6000
- Cooling: Water/Thermostatic Control
- Recommended Engine Oil: Yamalube® 4M (See owner’s manual)
- Recommended Fuel: Regular Unleaded (Minimum Pump Octane 87)
- Recommended Fuel Filtration: Yamaha 10-Micron Fuel/Water Separating Filter (external)
- Ethanol Blend Limit: 10% Maximum
- Gear Ratio: (30:15) 2.00:1
- Gear Shift: Forward, Neutral, Reverse
- Shaft Length: X = 25 in.
- Degree of Tilt: TBD
- Degree of Trim: -3 deg. through +16 deg.
- C.A.R.B. Rating: 3-Star
- Dry Weight: 276 kg (608 lb.)
- Mounting Centers: 28.6 in.
- Steering Angle (maximum): 32 deg. from center, either direction
- Warranty: 3-Year Pleasure, 3-Year Government, 1-Year Commercial
